We supply Single Sheave Swivel Fairleads,Double Sheave Swivel Fairleads etc types. All swivel fairlead are manufactured from high quality steel.
The fairleads are fitted with removable guide roller and hardened rope groove to ensure long-time usage.
Our fairleads can be designed as per your wire socket/ shackle size to reduce your installation problems.
If your swivel fairleads will be used on platform, need to get DNV/ABS etc,our rich project experience will help to smoothly meet the DNV / ABS class requirements ( material, load, suitable bearing etc ), help to reduce your project time and project cost.
STANDARD FEATURES
• Size: 19mm~76mm dia. wire
• Designed for breaking strength of wire with 90° wrap on sheave and +/- 90° rotation of swivel head
• Cast Steel Sheave / Plate Machined Sheave with Hardened Rope Groove for Longer Life
• Sealed Grease Lubricated Tapered Roller Bearings in Sheave and Swivelhead
• Weld Down Mounting Base
• Removable Guide Roller
• Epoxy Primer Coating
OPTIONAL FEATURES
•Tail Sheaves / Tail Rollers
•Bolt down mounting base
•Load monitoring system
•Special sheaves for high performance synthetic ropes
•Paint to your specifications
•Load test on request
•Third party certification, DNV & LR & ABS & BV certs are available.

Wire Rope Dia.		Sheave Dia.(mm)	Dimensions (mm)					Weight (kg)
(mm)	( inch )		A	B	C	T	H
25	1	254	486	420	722	20	277	210
32	1-1/4	305	570	492	839	20	342	365
38	1-1/2	406	780	782	1266	30	489	850
44	1-3/4	508	1064	914	1467	40	546	1520
50	2	610	1219	1067	1763	40	648	2600
64	2-1/2	762	1372	1219	2045	50	800	4000
76	3	938	1800	1500	2634	50	950	7200
82	3-1/4	1020	1800	2000	3186	50	1100	10800

We're able to supply HHP anchor+Swivel Shackle+Wire rope+Swivel Head Anchor Fairleads if you would like to save your time on choosing most suitable fittings (see below picture ).

Anchoring System Arrangement Plan
